Kiosk Printers

RX216-H150

A4 / 8-inch (216 mm) thermal transfer printer mechanism

Technical Sheet

구분	내용
Printing Method	Thermal line printing
Printing speed	Max. 100mm/s（Energy saving mode：Max50mm/s）
Printing width	216mm（1728 dots）
Resolution	203dpi
Character Set	ESC/POS bitmap printing solution
Font	ESC/POS bitmap printing solution
Paper type	Thermal receipt paper, Label
Paper width	Max. 216±1(mm)
Paper Diameter	Max. 150(mm)
Paper supply method	Auto feed
Reliability TPH	Max. 50Km 1. Font 12*24.western characters.print intermitterntly 2. Use standard thermal paper
Sensor	Paper in sensor, Black marked sensor, Head open sensor, Cutter position sensor, Near end sensor
Comnand	ESC/POS
Interface	USB, Serial(RS232)
Power	Input : 100-240V 50/60HZ 2.5A Output：DC24.0V 5.0A
cutter method	Full（Auto cutting）
Temperature Operating	0℃～50℃
Temperature Storage	-20℃～60℃
Humidity Operating	10%～80%RH
Humidity Storage	10%～90%RH
Printer size	88.4(L) X 265 (W) X 78(H) mm

Accssories
- 24V Power adaptor(with an AC power cord)
- 9pin female to female serial cable
- USB A-B Cable
옵션 장착 사진
Download
- SDK (윈도우)
  - REXOD_LIB_V30015_Sample.zip ()
- SDK (안드로이드)
  - REXOD_Android_SDK.zip ()
- Driver (윈도우)
  - DRIVER 윈도우.zip ()
- Utility (Test program)
  - RX2_Test_V02.zip ()
- Utility (Firmware update tool)
  - PrinterUpdateTool.zip ()
